| Outputs | 36 V DC/50 mA |
| Output impedance | 200 Ω / 200 Ω (XLR / Cinch, potential free) |
| Inputs | max. 36 V DC |
| Load impedance | 100 kΩ / 1 kΩ (XLR / Cinch, potentialfrei) |
| Weight kg | approx. 3.6 kg |
| Channel separation | > 75 dB |
| Harmonic distortion at nominal level | < 0.05 % |
| Max Level | + 6 dBu |
| Nominal level Output | 0 |
| Nominal level Input | 0 |
| Air humidity | 15 ... 90 % (non-condensing) |
| Signal-to-noise ratio | > 95 (> 85) dB |
| Current consumption @ 24 V DC | <150 mA |
| Transmission range | 20 ... 22000 Hz |
| Ambient temperature | -5 °C ... 55 °C |
| Dimensions | W: 483 mm H: 44 mm D: 345 mm (1 HU, 19") |
